NR 210

Routing, reinforcement steel screwing, drilling, milling, marking operations on PVC profiles are gathered in one machine controlled by computer.

Stacking of 10 cut to size profiles with reinforcement steel (max. 3,5 m. length).

The barcode reader enables arranging the sequence of the profile and processes.

Drain slot routing, drilling and routing at variable angles.

Automatic screwing of reinforcement steels.

Drilling of fixation, triple handle holes and hinge holes together with the reinforcement steel.

17” touchscreen enables easy access and control.

High performance Workstation PC with Intel® Core™ i5 3,1 Ghz microprocessor.

All error messages can be monitored from the screen by the software developed by Murat Machinery Software Department.

By online connection to the entire system, remote detection of malfunctions and maintenance is available.

Data transfer is available via network connection or USB interface.

Full integration with various window and door production software.
